Product Details:
Payment & Shipping Terms:
|
| Usage: | Fan, Home Appliance, Medical Apparatus,Personal Care,Power Tools | Type: | Micro Motor |
|---|---|---|---|
| Torque: | ≤80mN | Construction: | Permanent Magnet |
| Protect Feature: | Drip-proof | Speed(RPM): | 3000-20000rpm |
| Product Name: | Inrunner Brushless Dc Motor | Size: | D28mm*L38mm |
| Weight: | 75g | Motor Terminations: | 6PIN |
| High Light: | 6 PIN Inrunner Brushless DC Motor,30w micro inrunner brushless motor,80mNm inrunner bldc motor |
||
Specification:
| Size | D28mm*L37.6mm |
| Voltage | 6-26v |
| Unload Speed | 3000-20000rpm |
| Rated Torque | ≤30mNm |
| Max Torque | ≤80mNm |
| Wattage | 1-30w |
| Weight | Approx 75g |
| Characteristic | CW & CCW, Signal function available, Locked rotor protection, Stepless speed regulation, Low noise, Low EMI, Long life 10000-30000hrs |
Application:
Home Application: White Goods, Small Appliance, Fanner, Electric Curtain
Medical Apparatus: Medical Pump, Blood Pressure meter, surgery tools, medical stirrer, centrifugal machine
Power Tools: Air Oump,Water Pump, Vaccum Pump, Oxygenator Business Equipment: Printer, Copier, Projector, Scanner, Cash Register
Personal Care: Hair Dryer, Electric Shaver, Massage
Notice: Data in this typical specification sheet are for other certain customer. Voltage, rated torque, speed, current, power and shaft extension feature & dimension can be changed to meet customer specific requirement.
How To Know If The Motor Work For You?
1. Check The Motor Size
2. Check The Motor Voltage
3. Check The Motor Speed
4. Check The Motor Touque/Wattage
5. If No Suitable Parameters,Please Send An Inquiry
6. If Do Not Know Any Parameters,Please Send An Inquiry About "How you want the motor work for your application".
